Model | Capacity(t/h) | Max Rotary Speed(r/min) | Blade Dia.(mm) | Blade Distance(mm) |
TLSS16 | 6 | 112 | Φ160 | 160 |
TLSS20 | 10 | 100 | Φ200 | 200 |
TLSS25 | 18 | 90 | Φ250 | 250 |
TLSS32 | 25 | 80 | Φ320 | 320 |
TLSS40 | 48 | 71 | Φ400 | 355 |
TLSS50 | 70 | 65 | Φ500 | 400 |
It is mainly used to convey particle and powder materials such as grain, oils, feeding, oil seeds, feed, beans, etc.
l Mechanized auger blades with different thicknesses meet the wear resistance requirements of different processes;
l Intermediate suspension wear-resistant sliding bearings;
l Static balance checking after the auger is connected with shaft;
l Adopts the embedded tongue type to connect screw shaft with hanging bearing, the head and the tail shaft , installation and disassembly do not require axial movement, which is convenient for maintenance;
l The surface of the equipment has been pickled, phosphating, and anti-rust treatment, and sprayed with anti-rust baking paint, which is firm and does not fade;
