Model | Production（t/h） | Inlet and outlet diameter（mm） | Overall weight（kg） | Magnetic field intensity （GS） | Height（mm） | |
R=0.5 | R=0.75 | |||||
TCXT15 | 10 | 15 | Φ150 | 55 |
≥3000 | 600 |
TCXT20 | 20 | 30 | Φ200 | 80 | 600 | |
TCXT25 | 35 | 50 | Φ250 | 120 | 600 | |
TCXT30 | 45 | 70 | Φ300 | 170 | 720 | |
TCXT40 | 65 | 75 | Φ400 | 225 | 720 | |
Strong separation of magnetic metal inclusions in raw materials, widely used in feed, pharmaceutical, chemical and other industries
The magnetic core is made of the latest developed rare earth permanent magnet material, with a magnetic field strength of ≥ 3000GS and an iron removal efficiency of ≥ 99%
No power required, excellent overall performance
The outer cover of the permanent magnet is made of stainless steel, and the magnet block is made of composite permanent magnet material, with high magnetic field strength and strong suction force
No maintenance required at room temperature, no power consumption, year-round non demagnetization, ultra long operation
Automatic magnetic selection and cleaning can be achieved without manual labor, with extremely low usage costs
Multiple structural forms for users to choose from, with high magnetic core induction strength
